BY-9800FIP IP66 Outdoor 800W Frame LED Moving Head Light

Technical Specifications
Light Source：700W LED Color Temperature: 7000K
Beam Aperture: 138mm
Illuminance: 12000 Lux @ 15m, 5°beam angle
CRI: Standard mode Ra≥75, High CRI mode Ra≥90
Lifespan: ≥20,000 hours
Zoom Range: 5°–42°
Horizontal Scan: 540°with advanced magneto-electric positioning system, 16-bit resolution
Vertical Scan: 270 ° with advanced magneto-electric positioning system, 16-bit resolution
Color System: 1 color wheel (6 colors + white) Mixing System: CMY
continuous mixing
CTO: Adjustable 3200K–8000K

Fixed Gobos: 1 fixed gobo wheel with 8 static patterns + dynamic flame
effect
Rotating Gobos: 1 rotating gobo wheel with 7 interchangeable glass patterns
Shutter System: 4-framed precision shutter system, rotatable up to 90°
Prism: 3-facet prism, reversible rotation with adjustable speed
Focus: Motorized focus
Frost/Diffusion: 1 independent frost filter + 1 CRI enhancement filter
Strobe: 0–20Hz, optional random strobe and pulse strobe
Dimming: 0–100% linear dimming
Control Modes: DMX512, standalone, sound-activated, RDM
Channels: 38/40CH
Display: Touch control interface showing temperature and LED brightness
Input Voltage: AC 90–240V, 50/60Hz
Power Connector: Neutrik power CON or 16A waterproof socket (optional)
Signal Connector: Neutrik XLR or 3-pin waterproof signal connector
Power Consumption: 850W
Power Factor: 0.85
Operating Environment: -20°C to 45°C
Dimensions: 41.5*24*76.6 cm
Net Weight: 28 kg
Housing: Magnesium alloy casing with black outdoor-grade paint
Cooling System: Ultra-quiet forced-air cooling + magnesium alloy body +
copper heat pipe radiator
Protection Rating: IP66
